Rope eye with metric male thread (M)

제품 라인업 — Wire ropes assemblies · Rope eye with external thread

Rope eye with metric male thread (M)
No. ø c M s WLL kN kg
20270-0050-01 6 22 M12 155 4.9 0.0500
20270-0080-01 7 25 M14 155 7.84 0.0800
20270-0120-01 8 27 M16 165 11.76 0.1400
20270-0160-01 9 34 M18 190 15.69 0.1800
20270-0200-01 10 35 M20 215 19.61 0.2800
20270-0250-01 12 44 M24 255 24.51 0.4200
20270-0400-01 14 55 M30 300 39.22 0.8000
20270-0630-01 16 68 M36 360 61.76 1.4500
20270-0800-01 20 75 M42 425 78.43 2.0000
20270-1250-01 26 95 M52 530 123 3.5000

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
