Rope eye with round male thread (Rd)

제품 라인업 — Wire ropes assemblies · Rope eye with external thread

Rope eye with round male thread (Rd)
No. ø c Rd s WLL kN kg
20270-0050-02 6 22 12 155 4.9 0.0500
20270-0080-02 7 25 14 155 7.84 0.0800
20270-0120-02 8 27 16 165 11.76 0.1400
20270-0160-02 9 34 18 190 15.69 0.1800
20270-0200-02 10 35 20 215 19.61 0.2800
20270-0250-02 12 44 24 255 24.51 0.4200
20270-0400-02 14 55 30 300 39.22 0.8000
20270-0630-02 16 68 36 360 61.76 1.4500
20270-0800-02 20 75 42 425 78.43 2.0000
20270-1250-02 26 95 52 530 123 3.5000

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
