Welaki sling with locking device swaged and protective PVC tube

제품 라인업 — Wire ropes assemblies · Wire rope slings

Welaki sling with locking device swaged and protective PVC tube
No. ø L WLL kN kg
20123-1400-010 14 1 20.78 1.7300
20123-1400-015 14 1.5 20.78 2.1000
20123-1400-020 14 2 20.78 2.4600
20123-1400-025 14 2.5 20.78 3.0000
20123-1500-010 15 1 23.53 2.0000
20123-1500-015 15 1.5 23.53 2.3300
20123-1500-020 15 2 23.53 3.0000
20123-1500-025 15 2.5 23.53 3.3000
20123-1600-010 16 1 26.47 2.4500
20123-1600-015 16 1.5 26.47 3.0000
20123-1600-020 16 2 26.47 3.4200
20123-1600-025 16 2.5 26.47 3.9500
20123-1800-010 18 1 33.33 3.0000
20123-1800-015 18 1.5 33.33 3.6000
20123-1800-020 18 2 33.33 4.2500
20123-1800-025 18 2.5 33.33 4.8300

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
