Hoisting rope rotation-resistant cat. 2 / ASTM 18 x 7 + WC

제품 라인업 — Wire ropes · Hoist ropes / assembly ropes

Hoisting rope rotation-resistant cat. 2 / ASTM 18 x 7 + WC
No. ø Constr MBL kN kg
10300-0400 4 18 x 7 + WC 10 0.0641
10300-0500 5 18 x 7 + WC 16 0.1000
10300-0600 6 18 x 7 + WC 23 0.1450
10300-0650 6.5 18 x 7 + WC 27 0.1700
10300-0700 7 18 x 7 + WC 31 0.1970
10300-0800 8 18 x 7 + WC 41 0.2570
10300-0900 9 18 x 7 + WC 52 0.3260
10300-1000 10 18 x 7 + WC 64 0.4020
10300-1100 11 18 x 7 + WC 77 0.4860
10300-1200 12 18 x 7 + WC 92 0.5790

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
