Open spiral strand rope plastic-coated
No. Color ø Constr MBL kN kg
10840-0450 transparent 0.45 / 0.81 1 x 7 INOX 0.1 0.0040
10840-0900 transparent 0.9 / 1.2 6 x 7 + WC INOX 0.6 0.0045
10840-1016 transparent 1 / 1.6 1 x 19 INOX 0.8 0.0100
10840-1520 transparent 1.5 / 2 1 x 19 INOX 2.2 0.0130
10840-2030-3 #ffffff 2 / 3 6 x 7 + WC INOX 2.4 0.0220
10840-3040 transparent 3 / 4 6 x 19 + WC INOX 4.6 0.0550
10840-3040-2 #000000 3 / 4 6 x 19 + WC INOX 4.6 0.0550
10840-3050-3 #ffffff 3 / 5 6 x 7 + WC INOX 4.6 0.0550
10840-3050-4 #3574dc 3 / 5 6 x 19 + WC INOX 4.6 0.0550
10840-3050-5 #b7b7b7 3 / 5 6 x 19 + WC INOX 4.6 0.0550
10840-4060-3 #ffffff 4 / 6 6 x 7 + WC INOX 9 0.0950
10840-4060-4 #3574dc 4 / 6 6 x 19 + WC INOX 8.3 0.0850

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
