Standard round strand rope Fixed length

제품 라인업 — Wire ropes · Standard wire ropes

Standard round strand rope Fixed length
No. ø Constr L MBL kN kg
10100-0100-10 1 1 x 19 10 0.9 0.0330
10100-0100-100 1 1 x 19 100 0.9 0.4000
10100-0100-20 1 1 x 19 20 0.9 0.0650
10100-0150-100 1.5 6 x 7 + WC 100 1.4 0.9000
10100-0200-05 2 6 x 7 + FC 5 2.5 0.0790
10100-0200-10 2 6 x 7 + FC 10 2.5 0.1180
10100-0200-100 2 6 x 7 + FC 100 2.5 1.4000
10100-0200-20 2 6 x 7 + FC 20 2.5 0.2940
10100-0250-100 2.5 6 x 7 + FC 100 3.6 2.1000
10100-0300-05 3 6 x 19 + FC 5 4.9 0.1170
10100-0300-10 3 6 x 19 + FC 10 4.9 0.2340
10100-0300-100 3 6 x 19 + FC 100 4.9 3.2000
10100-0300-20 3 6 x 19 + FC 20 4.9 0.4530
10100-0400-05 4 6 x 19 + FC 5 8.7 0.2000
10100-0400-10 4 6 x 19 + FC 10 8.7 0.4220
10100-0400-100 4 6 x 19 + FC 100 8.7 5.3000
10100-0400-20 4 6 x 19 + FC 20 8.7 0.8490
10100-0500-05 5 6 x 19 + FC 5 13.6 0.3110
10100-0500-10 5 6 x 19 + FC 10 13.6 0.6160
10100-0500-100 5 6 x 19 + FC 100 13.6 7.8000
10100-0600-05 6 6 x 19 + FC 5 19.6 0.4330
10100-0600-10 6 6 x 19 + FC 10 19.6 0.8440
10100-0600-100 6 6 x 19 + FC 100 19.6 12.5000
10100-0800-100 8 6 x 19 + FC 100 34.8 22.1000
10100-1000-100 10 6 x 19 + FC 100 63.3 34.6000

Labeling according to the technical drawing. Technical changes are reserved. The information on this website is provided without guarantee of completeness.

↑
